For steel rolling and bar & wire engineering production lines, a high-performance automatic steel strapping machine is the key to optimizing bundling processes, boosting production efficiency, and ensuring steel transportation safety.
Our industrial-grade automatic steel strapping machine is custom-built for high-intensity steel production scenarios, integrating mechanical, hydraulic, and automatic control technologies. With heavy-duty configuration, high-precision performance, and humanized structural design, it perfectly meets the automatic bundling needs of large-weight steel profiles—an ideal choice for metallurgical and steel processing enterprises.
Core Performance Advantages
🔹 High Efficiency & Ultra-High Success Rate
- Single strapping cycle: 8~15 seconds
- Strapping success rate: ≥99.8%
- Adapt to fixed-length steel profiles: 6m~12m (9 strapping passes for 12m profiles, fully customizable)
- Realize fast, stable bundling and greatly improve overall production line efficiency
🔹 Large-Specification Adaptability
- Bundling size range: 300×300 – 650×650mm (W×H)
- Max bundling weight: 4000KG~7000KG
- Applicable steel types: All profiles, steel pipes, round steel
- Meets batch bundling requirements of industrial large-weight steel products
🔹 Strong Environmental Adaptability
- Direct bundling for high-temperature steel: ≤600℃
- Working ambient temperature: -10℃~40℃
- Resists the complex working environment of metallurgy and steel rolling production
🔹 Intelligent Dual Control Mode
- Remote automatic operation: Realizes interlock communication with production lines, seamless connection to automatic processes, minimal manual intervention
- Local manual operation: Facilitates debugging, maintenance and emergency operation, simple and flexible to operate
Ingenious Structural Design & Core Highlights
✅ Firm Strapping, No Loosening During Transportation
- Oil cylinder tightening technology with large tightening force for ultra-firm bundling
- Patented knot flattening device: Flattens knot ends to fit steel bundles, avoids scratching, adapts to roller transportation
- Exclusive patented composite hydraulic cylinder wire twisting mechanism: Twisting angle ≥630°, spiral movement for neat, beautiful knots (no additional stress), eliminates traditional “triangle area” defect
✅ Low Use Cost & Simple Operation
- Strapping material: Ordinary Q195 hot-rolled wire rod (Φ6~8mm, recommended Φ6.5mm) — no additional processing, easy to purchase, low cost
- Oil cylinder wire pressing + double-wheel wire feeding mechanism: Simple wire threading, stable and smooth conveying
- Suspended wire threading groove: Automatically discharges oxide scale, no blockage, ultra-low failure rate
✅ Convenient Maintenance, No Production Interruption
- Integrated trolley design + walking device: Manually push to enter/exit roller tables, supports off-line debugging & maintenance (no production stop)
- Centralized component installation: Clear structure, easy daily inspection and spare part replacement
✅ High-Quality Hydraulic System & Long Service Life
- Hydraulic pipeline: Precision galvanized seamless steel pipe + imported cylinder seals (high cleanliness, low leakage)
- System configuration: 340L large-capacity oil tank + fan cooling (stable operation under high-intensity conditions); adjustable working pressure (9~14MPa)
- Power supply: Three-phase four-wire AC380V+PE 50HZ, total installed capacity 18KW (easy to connect to factory power)
Heavy-Duty Configuration & Strict Manufacturing Standards
🔸 Basic Equipment Parameters
- Single machine weight: ~5 Tons
- Overall dimensions: 4930×1650×3260mm (L×W×H)
- Packing method: Wooden case + steel reinforcement (complies with national export standards)
🔸 Well-Known Brand Core Components
We select high-quality core parts from top suppliers to ensure long-term stable operation:
- Motor: Siemens Beder
- Bearings: Luoyang Bearing Factory / Harbin Bearing Factory
- Hydraulic motor: Taiwan Imported
- Hydraulic pump/valve: Beijing HUADE / Taiwan Northman
- Detection components: German Imported / Taiwan Northman
🔸 Strict Quality Control
- Complies with over 60 national and metallurgical industry high standards (GB/T 13384, YB/T 036.19-92, etc.)
- Strict process quality control and full-process inspection & acceptance
- Guaranteed industrial-grade product quality
Comprehensive After-Sales Service & Commercial Support
📌 Complete Technical Data
- Provide a full set of Chinese-English bilingual technical documents
- Include civil foundation drawings, electrical schematics, PLC programs, operation & maintenance manuals, spare parts lists, etc.
- Facilitate overseas project construction and daily equipment maintenance
📌 On-Site Technical Service
- Professional technicians for on-site installation and commissioning guidance
- Handover only after qualified joint commissioning
- On-site training for operators (operation, daily maintenance, fault handling)
📌 Long-Term Quality Assurance
- Extended warranty period: Valid from the equipment commissioning, with an upper time limit after delivery
- Free maintenance and faulty part replacement for equipment-specific issues during the warranty period
📌 Flexible Delivery & Commercial Terms
- Customizable delivery time and location, responsible for domestic transportation
- Export-standard packaging for international shipping
- Support bulk project procurement, flexible payment terms available for project needs
Applicable Scenarios
This automatic steel strapping machine is the core supporting equipment for steel rolling production lines and bar & wire engineering projects, widely used in:
Metallurgical processing | Steel manufacturing | Profile production | Steel pipe production
It provides a professional automatic bundling solution for straight steel profiles, steel pipes, round steel and other products, helping enterprises:
✅ Optimize production line processes and improve automation efficiency
✅ Reduce manual operation and labor costs
✅ Ensure steel transportation safety and minimize loss
✅ Realize standardized bundling and improve product delivery quality
As a professional industrial steel strapping equipment provider, we are committed to building a stable and efficient bundling link for steel production enterprises, and escorting the high-quality development of your production line!
